COBHAM SAILOR 6000 - Internal Cable Overview

4-2
Chapter 4: Installation cables
98-131571-B
4.2 Internal cable overview
Cable No. Cable type From/To From/To Part No. Signal Conn.
C7.1.00 PL-PL 62xx VHF RF-Plug 527830 VHF Main RF 1:1
C7.1.01 PL-PL 62xx VHF RF-Plug 527830 VHF DSC RF 1:1
C7.2.00 12-12 pole LTW CU 630x MF/HF 37-131080 CANBUS 1:1
C7.2.01 10-10 pole LTW CU 630x MF/HF 37-131079 ACC 1:1
C7.2.02 10-10 pole LTW HandsetBulkPlug 37-131081 AF / PTT 1:1
C7.2.03 Ethernet CAT5E CU 630x MF/HF SAILOR 6197 Switch 37-206122-150 Ethernet 1:1
C7.2.04 12-12 pole LTW 62xx VHF 37-131080 AUX 1:1
C7.2.05 10-10 pole LTW 62xx VHF 37-131079 ACC 1:1
C7.2.06 10-10 pole LTW HandsetBulkPlug 37-131081 AF / PTT 1:1
C7.2.07 Ethernet CAT5E 62xx VHF SAILOR 6197 Switch 37-206122-150 Ethernet 1:1
C7.2.08 NMEA2000 Message Terminal 37-131510 CANBUS 1:1
C7.2.09 USB Message Terminal Printer Supplied Data 1:1
C7.2.10 Ethernet CAT5E Message Terminal SAILOR 6197 Switch 37-206122-150 Ethernet 1:1
C7.2.11 8 pole mine DIN Printer Printer switch Supplied Control 2
C7.3.10 Power Cable 62xx VHF Supplied DC supply M
C7.3.11 Power Cable Message terminal Supplied DC supply M
C7.3.12 Power Cable Printer Supplied DC supply M
C7.3.13 Power Cable 6090 Power Conv. 37-133053
C8.2.00 12-12 pole LTW CU 630x MF/HF 37-131080 CANBUS 1:1
C8.2.01 10-10 pole LTW CU 630x MF/HF 37-131079 ACC 1:1
C8.2.02 10-10 pole LTW HandsetBulkPlug 37-131081 AF / PTT 1:1
C8.2.03 Ethernet CAT5E CU 630x MF/HF SAILOR 6197 Switch 37-206122-150 Ethernet 1:1
C8.2.06 10-10 pole LTW HandsetBulkPlug 37-131081 AF / PTT 1:1
C8.2.08 NMEA2000 Message Terminal 37-131510 CANBUS 1:1
C8.2.09 USB Message Terminal Printer Supplied Data 1:1
C8.2.10 Ethernet CAT5E Message Terminal SAILOR 6197 Switch 37-206122-150 Ethernet 1:1
C8.2.11 8 pole mine DIN Printer Printer switch Supplied Control
C8.2.12 NMEA2000 Message Terminal 37-131510 CANBUS 1:1
C8.2.14 USB Message Terminal Printer Supplied Data 1:1
C8.2.15 Ethernet CAT5E Message Terminal SAILOR 6197 Switch 37-206122-150 Ethernet 1:1
C8.2.16 8 pole mine DIN Printer Printer switch Supplied Control 2
C8.3.11 Power Cable Message Terminal Supplied DC supply M
C8.3.12 Power Cable Printer Supplied DC supply M
C8.3.13 Power Cable Printer Supplied DC supply M
C8.3.14 Power Cable Message Terminal Supplied DC supply M
C9.2.18 Ethernet CAT5E SAILOR 6197 Switch SAILOR 6197 Switch 37-206570-025 Ethernet 1:1
C9.3.16 Power Cable SAILOR 6197 Switch 37-131395 DC supply M
C9.3.17 Cable, 4 pole Light Control 37-126772 DC supply 4
C9.3.18 Cable, 2 pole Light/Gooseneck 37-126773 DC supply 3
C9.3.19 Power Cable SAILOR 6197 Switch 37-131395 DC supply M
Additional cables can be ordered at Cobham SATCOM eshop.
