COBHAM SAILOR 6000 User Manual

Chapter 2: Installation
2-1
Installation
98-131571-B
Chapter 2
2 Installation
2.1 Dimensions
Console type numbers and part numbers refer to console hardware only, i.e. an empty console with only dimable
light and connection board(s) installed.
Equipment illustrated for reference only.
Type 6334C
2 pcs. SAILOR 630x MF/HF Control Unit
3 pcs. SAILOR H1252B USB/Parallel Printer
3 pcs. SAILOR 6006 Message Terminal
Weight:
excl.units 60kg
incl.units 89kg
Type 6333D
1 pcs. SAILOR 630x MF/HF Control Unit
1 pcs. SAILOR 62xx VHF Radio
2 pcs. SAILOR H1252B USB/Parallel Printer
2 pcs. SAILOR 6006 Message Terminal
Weight:
excl.units 45kg
incl.units 65kg
Type 6333B
1 pcs. SAILOR 630x MF/HF Control Unit
2 pcs. SAILOR H1252B USB/Parallel Printer
2 pcs. SAILOR 6006 Message Terminal
Weight:
excl.units 45kg
incl.units 65kg
Type 6333C
1 pcs. SAILOR 630x MF/HF Control Unit
2 pcs. SAILOR H1252B USB/Parallel Printer
2 pcs. SAILOR 6006 Message Terminal
Weight:
excl.units 45kg
incl.units 65kg
1645mm
405mm
500mm
380mm
99-132159
MF/HF
MF/HF
TelexTelex Mini-C
1245mm
405mm
500mm
380mm
99-132160
Mini-C
MF/HF
VHF
Mini-C
1245mm
405mm
500mm
380mm
99-132211
Telex Mini-C
MF/HF
1245mm
405mm
500mm
380mm
99-132161
Mini-C Mini-C
MF/HF
