COBHAM SAILOR 6000 User Manual

Chapter 2: Installation
2-11
Installation
98-131571-B
Factorycongurationoftheconsole
2.8 Factorycongurationoftheconsole
Whenthe6000GMDSSConsolesystemisorderedalongwiththerelevantequipmentsetsandServicePackpart
number(ServicePackdenotesfactoryinstallationofunitsinconsole)thecongurationoftheequipmentwillbe
as per the following notation:
In consoles with two handsets and hence two radio control units, the left side handset is always associated with
the upper most control unit (MF/HF CU).
SuppliedwiththeConsoleaccessorykitareselfadhesivelabelswhichmaybeusedtomarktherespectivehandsets
forMF/HFandVHF,foreaseofidentication(Fig.1).
1245mm
405mm
500mm
380mm
99-132160
Mini-C
MF/HF
VHF
Mini-C
Fig.1
Equipmentconguration:
Withtwo6006mini-Cinstalled(Fig.2)theprinterandMessageTerminal/keyboardassociatedwith#1mini-C(part
ofprimaryGMDSSequipment)isinstalledinthelefthandsideoftheconsole.The#2mini-Cequipment(partof
duplicationGMDSSequipment)isinstalledintherighthandside.BothMessageTerminalswillbeconguredwith
the Capsat application software program.
TheMF/HFcontrollerisinstalledastheuppermostunit(aspartofSystem#1orprimaryGMDSSequipment)and
the#1VHFinstalledbelowtheMF/HFControlUnitalsoaspartofthe#1SystemorprimaryGMDSSequipment.
1245mm
405mm
500mm
380mm
99-132160
Mini-C
MF/HF
VHF
Mini-C
Fig.2
VHF
MF/HF
MF/HF 2
#1 #2
#1printer #2printer
