COBHAM SAILOR 6560 - The GNSS or DGNSS System

Chapter 1: Introduction
2 The GNSS or DGNSS system
The GNSS or DGNSS system
The GNSS/DGNSS Receiver is available in variants as listed in table 1.
Depending on the antenna used the Receiver will either be a GNSS or a
DGNSS Receiver. Using the SAILOR 6285 GNSS Antenna - Active gives a
GNSS Receiver variant and the SAILOR 6286 DGNSS Antenna - Active gives
a DGNSS Receiver variant.
Both variants can be controlled by the SAILOR 6004 Control Panel. The
Control Panel is connected to the GNSS/DGNSS Receiver through a LAN
connection.
Features
 Position calculation with GPS and/or GLONASS satellites.
 Reception and use of differential corrections from SBAS, RTCM SC-104
via a serial interface or the integrated radio beacon receiver.
1
 RAIM calculation according to IEC 61108-1. Estimates the calculated
positions accuracy and monitors the signal integrity.
 SBAS corrections from EGNOS, MSAS, WAAS, GAGAN and SDCM.
 Automatic or manual radio beacon station selection.
1
 Support for other datums, including a user defined.
 Serial inputs and outputs according to IEC 61162-1/2. Fully
configurable for each port.
 Light Weight Ethernet interface according to IEC 61162-450. Fully
configurable.
 Alert management according to MSC.302. Fully configurable.
 Support for High Speed Craft (HSC).
 Antenna offset correction.
 Anchor Watch.
1. DGNSS only
