Appendix A: Specifications
54 SAILOR 6004 Control Panel
SAILOR 6004 Control Panel
Item Specifications
Mounting method Flush mount or bracket
Voltage 10.8 to 31.2 VDC
Power consumption Typical: 18 W active
Peak: 42 W
3.15 A internal fuse (non-serviceable)
Audio input Up to 6 W in 8 Ohm
Interfaces 2 x Ethernet (10/100 Mbit/s)
Accessories connector
Auxiliary connector
Compliance
• IEC 60945
• IEC 60950-1
IP rating IP54
a
Ambient temperature -15 °C to 55 °C
Storage temperature -30 °C to 80 °C
Compass safe distance 0.6 m
Dimensions W x H x D 191 mm x 145 mm x 61 mm (without mounting
bracket)
Weight 1.1 kg (1.25 kg with mounting bracket)
Resolution of the
display
800x400 pixels
Screen size 152.5 x 91.44 mm
Table 19: Control Panel specifications
a. Estimated.
