Appendix A
AAAAA
Specifications
Specifications A
This appendix contains the technical specifications and a list of the
supported NMEA sentences.
SAILOR 6588 GNSS/DGNSS Receiver
Item Specification
GNSS receiver 30 channel GPS and GLONASS receiver
Position-Fix time cold start 45 s
PPS accuracy 15 ns
Weight 1.3 kg
Dimensions (L x W x H) 190 x 270 x 24.5 mm
Equipment class Protected, according to IEC 60945
Input voltage 10.8 VDC to 31.2 VDC
Power consumption 5 W (0.2 A @24 VDC input voltage)
Heat dissipation < 10 W
Operating temperature -15 °C to +55 °C (Operational)
Storage temperature -30 °C to +70 °C (Storage)
Compass Safe Distance 30 cm (standard magnetic compass)
20 cm (Emergency magnetic compass)
Beacon receivers 283.5 - 325 kHz MSK three parallel receivers
Connector for GNSS or DGNSS
antenna
TNC female
Connection to Control Panel LAN
Table 16: GNSS/DGNSS Receiver specifications
