Chapter 3: Service & maintenance
44 Troubleshooting guide
No beacon
correction
The (lower) beacon
status “LED” in the
Overview screen is
absent.
The CORR LED on the
receiver is lit and red.
Check if Differential Beacon
Correction/External RTCM
Correction (DGNSS/GNSS) is enabled in
Settings > Radio Beacons.
The (lower) “LED” in
the Overview
screen is amber.
The CORR LED on the
receiver is lit and red.
WARNING:
“Differential
Integrity status” is
active.
Check the antenna cable to the antenna.
Check beacon selection mode is correct.
Use for example Automatic Mode.
No SBAS
correction
The CORR LED on the
receiver is lit and red.
Check if SBAS Correction Systems is
enabled in Settings.
Device failure If any of the checks and tests described
in this section does not assist in resolving
the difficulties experienced in the
operation and/or performance of the
installation, a fault may have developed
in the GNSS/DGNSS System. When
contacting an authorized representative,
be sure to provide as much information
as possible describing the observed
behavior - also including the type of the
GNSS/DGNSS units, serial number, and
software release version. You find this
information in the setup menu of the
connected Control Panel.
Problem Symptom Remedy
