COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix A: Technical specifications A-3
Specifications SAILOR 1000 XTR GX-R2
Tracking Receiver Internal "all band/modulation type" including e.g. power,
DVB-S2X, GSC and modem RSSI
Satellite acquisition Automatic - with Gyro/GPS Compass input. Support for
gyro free operation.
Elevation Range -20° to +120°
Cross Elevation +/-37°
Azimuth range Unlimited (Rotary Joint)
Ship motion, angular Roll ±30° (6 sec), Pitch ±15° (5 sec), Yaw ±10° (8 sec)
Ship, turning rate and
acceleration
15°/S and 15°/S2
ADU motion, linear Linear accelerations ±2.5 G max any direction
Vibration, operational Sine: EN60945 (8.7.2), DNV 2.4A, MIL-STD-167-1 (5.1.3.3.5).
Random: Maritime
Vibration, survival Sine: EN60945 (8.7.2) dwell, MIL-STD-167-1 (5.1.3.3.5)
dwell.
Random: EN60721-3-6 class 6M3 mod. by EN60721-4-6
Shock EN60721-3-6 class 6M3 mod. by EN60721-4-6.
MIL-STD-810F 516.5 (Proc. II)
Temperature (ambient) Operational: -25°C to +55°C / -13°F to +131°F
Storage: -40°C to +85°C / -40°F to +185°F
With SAILOR SMART heater
option: P/N: 407090-001
Operational: -55°C to +55°C / -67°F to +131°F
Humidity 95%, condensing
Rain / IP class EN60945 Exposed / IPx6
Wind 80 knots operational, 110 knots survival
Ice, survival 25 mm / 1"
Solar radiation 1120 W/m2 to MIL-STD-810F 505.4
Compass safe distance 1.5 m / 59" to EN60945
Maintenance, scheduled None
Maintenance, unscheduled All electronic, electromechanical modules and belts are
replaceable through hatch.
Built In Test Power On Self-Test, Person Activated Self-Test and
Continuous Monitoring w. error logging.
Table A-1: SAILOR 1000 XTR GX-R2 specifications (Continued)
