COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix A: Technical specifications A-2
Specifications SAILOR 1000 XTR GX-R2
A.1 Specifications SAILOR 1000 XTR GX-R2
The table below shows specifications for the most recent SAILOR 1000 XTR GX-R2
system with ADU P/N 407509C-00541 and 407509D-00541 (with eDome). Some
specifications may vary slightly if you have an earlier variant, refer to Specifications,
SAILOR 1000 XTR GX-R2 w. Composite radome on page A-5.
SYSTEM SPECIFICATIONS
Reflector size 103 cm / 40.6"
Type approvals Inmarsat
Certification Compliant with CE (Maritime), ETSI, FCC
System power supply range 100-240 VAC, 50-60 Hz
System power consumption 4.5W: 135W typ. 185W max. (excl. modem)
9.0W: 180W typ. 215W max. (excl. modem)
FREQUENCY BAND: Ka-band (GX-R2)
Rx 17.7 to 20.2 GHz
Tx 27.5 to 30.0 GHz
ANTENNA CABLE & CONNECTORS
BDU to ADU cable Coax cable (50 Ω) for Rx, Tx, MoCA and DC power on a
single cable
ADU cable connector Female N-Connector (50 Ω)
BDU cable connector Female N-Connector (50 Ω)
SAILOR XTR ABOVE DECK UNIT (ADU)
Antenna type, pedestal 3-axis stabilized tracking antenna with integrated GNSS
supporting GPS, GLONASS and Beidou
Antenna type, reflector system Reflector/sub-reflector, ring focus
Transmit Gain
a
47.6 dBi typ. @ 29.5 GHz (incl. radome)
Receive Gain
a
44.4 dBi typ. @ 19.7 GHz (incl. radome)
System G/T
a
21.0 dB/K typ. @ 19.7 GHz, at ≥10° elevation and clear sky
(incl. radome)
GX-R2 transceiver output power 4.5 Watt or 9.0 Watt
EIRP
a
4.5 W: 54.1 dBW (incl. radome)
9.0 W: 57.1 dBW (incl. radome)
LNB Inmarsat GX-R2 transceiver
Polarisation Circular (RHCP, LHCP), Co-Pol and X-Pol
Table A-1: SAILOR 1000 XTR GX-R2 specifications
