COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix F: Event messages F-2
List of events
F.2 List of events
(09-01-2023)
ID Module Type Description Explanation
08061-0 ADM WARNING VMU linux shell
password
The specified password (root) for the
satellite modem is not accepted by the
modem.
08062-0 ADM WARNING VMU debug shell
password
The specified password (user) for the
satellite modem is not accepted by the
modem.
08069-0 ADM WARNING Blocking Zone The antenna has entered a blocking zone.
0806A-0 ADM WARNING VMU connection The BDU has lost connection to the
satellite modem.
0806C-0 ADM WARNING VMU frequency
setup
There is a mismatch in the frequency
setup. Probably the satellite modem is
not configured correctly to match the
requirements of the BDU and antenna. A
common mismatch is the absence of Rx
or Tx LO parameter in the satellite
modem.
08073-0 ADM WARNING Slave
connection
The system is configured as a dual
antenna master, but no dual antenna
slave is connected to it. Either disable the
dual antenna master in the web interface
or configure a another system as a dual
antenna slave.
08074-0 ADM WARNING Master
connection
The system is configured as a dual
antenna slave, but it was not possible to
connect to the dual antenna master.
Check that the IP address entered in the
modem profile is correct and check that
the master and slave systems are
physically connected as described in the
manual.
08075-0 ADM WARNING Rx cable
calibration
Calibration of the antenna cable failed.
The cable could be defective, too long,
connectors not properly connected, or
the BDU or ADU hardware could be
defective.
Table F-1: Event messages
