98-175666-D Appendix A: Technical specifications A-10
Specifications SAILOR XTR BDU 7516A
A.3 Specifications SAILOR XTR BDU 7516A
BELOW DECK UNIT (BDU) 7516A
Dimensions 1U 19" rack mount
HxWxD: 4.4 x 48 x 33 cm / 1.73" x 18.9" x 13"
Weight 3.6 kg / 7.9 lb
Temperature (ambient) Operational: -25°C to +55°C / -13°F to +131°F
Storage: -40°C to +85°C / -40°F to +185°F
Humidity EN 60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.3 m / 12" to EN60945
Interfaces 1 x Male N-Connector for antenna RF Cable (50
Ω)
with automatic cable loss compensation.
2 x F-Connectors (75
Ω) for Rx and Tx to VSAT modem
1 x Ethernet Data (VSAT Modem Control)
2 x Ethernet (User)
1 x Ethernet (Remote access)
1 x Ethernet for Service and Configuration
1 x RJ-45, RS-422 Data (VSAT Modem Control)
1 x RJ-45, RS-232 Data (VSAT Modem Control)
1 x RJ-45, NMEA 0183 (RS-422 / RS-232) for Gyro/GPS
Compass and external GPS input
1 x RJ-45, 4 x General purpose GPIO, Tx mute and Rx
lock.
1 x AC Power Input
1 x Grounding bolt
User Interface Web interface, OLED display (red), 5 pushbuttons, 3
discrete indicator LEDs and On/Off switch, TX Mute
and Modem Lock indicator.
Temperature control Built-in fan
No transmit zones Programmable, 8 zones with azimuth and elevation
Real-time blocking map recorder
Remote management and IoT HTTPS, SSH, Telnet, SNMP Traps, Syslog, CLI,
Diagnostic, Statistic, RESTful, MQTT
Table A-6: BDU specifications
