COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix A: Technical specifications A-9
Specifications SAILOR 600 XTR GX-R2
Specifications for other variants are listed in the following tables (see P/N in the table
headers). These tables only show the specifications that are different from those of the
latest variant (in section A.2 and ).
P/N 407506A-00541 SAILOR 600 XTR GX-R2 ADU (4.5W)
(carbon pedestal and eDome)
Transmit Gain 44.0 dBi typ. @ 29.5 GHz (Incl. eDome)
Receive Gain 40.3 dBi typ. @ 19.7 GHz (Incl. eDome)
System G/T 16.8 dB/K typ. @ 19.7 GHz, at ≥10° elevation and clear sky (incl.
radome)
EIRP 50.5 dBW (incl. radome)
Dimensions (eDome) Height: H 92 cm / 36.2"
Diameter: Ø 84 cm / 33.1"
Weight 35 kg / 77 lb
Table A-4:
SAILOR 600 XTR GX-R2, specifications with carbon pedestal and eDome
P/N 407506A-00542 SAILOR 600 XTR GX-R2 ADU (4.5W)
(aluminum pedestal and composite radome)
Transmit Gain Same as in Table A-3 on page A-8
(P/N 407506A-00540 SAILOR 600 XTR GX-R2 ADU (4.5W), w.
carbon pedestal and composite radome)
Receive Gain Same as in Table A-3 on page A-8
System G/T Same as in Table A-3 on page A-8
EIRP Same as in Table A-3 on page A-8
Dimensions Same as in Table A-3 on page A-8
Weight 44 kg /97 lb
Table A-5:
SAILOR 600 XTR GX-R2, specs with aluminum pedestal and composite radome
