COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix A: Technical specifications A-6
Specifications SAILOR 600 XTR GX-R2
A.2 Specifications SAILOR 600 XTR GX-R2
The table below shows specifications for the most recent SAILOR 600 XTR GX-R2
systems with ADU P/N 407506A-00543 (4.5 W with aluminum pedestal and eDome) or
ADU P/N 407506D-00542 (9 W with aluminum pedestal and composite radome). Some
specifications may vary slightly if you have an earlier variant, refer to Specifications,
earlier variants of SAILOR 600 XTR GX-R2 on page A-8.
SYSTEM SPECIFICATIONS
Reflector size 65 cm / 25.5"
Type Approvals Inmarsat
Certification Compliant with CE (Maritime), ETSI, FCC
System power supply range 100 - 240 VAC, 50-60 Hz
Total system power
consumption
135 W typical, 185 W max (excl. Modem)
FREQUENCY BAND: Ka-band (GX-R2)
Rx 17.7 to 20.2 GHz
Tx 27.5 to 30.0 GHz
ANTENNA CABLE & CONNECTORS
BDU to ADU cable Coax cable (50 Ω) for Rx, Tx, MoCA and DC power on a single
cable
ADU cable connector Female N-Connector (50 Ω)
BDU cable connector Female N-Connector (50 Ω)
ABOVE DECK UNIT (ADU)
Antenna type, pedestal 3-axis stabilized tracking antenna with integrated GNSS
supporting GPS, GLONASS and Beidou
Antenna type, reflector
system
Reflector/sub-reflector, ring focus
Transmit Gain
a
44.0 dBi typ. @ 29.5 GHz (Incl. radome)
Receive Gain
a
40.3 dBi typ. @ 19.7 GHz (Incl. radome)
System G/T
a
16.8 dB/K typ. @ 19.7 GHz, at ≥10° elevation and clear sky (incl.
radome)
GX-R2 transceiver output 4.5W
EIRP
a
4.5 W: 50.5 dBW typ. @ 29.5 GHz (incl. radome)
9.0 W: 53.5 dBW typ. @ 29.5 GHz (incl. radome)
LNB Inmarsat GX-R2 transceiver
Table A-2: SAILOR 600 XTR GX-R2 (4.5 W) specifications
