98-175666-D Appendix A: Technical specifications A-7
Specifications SAILOR 600 XTR GX-R2
Polarisation Circular (RHCP, LHCP) independent controlled for Rx and Tx
Tracking Receiver Internal "all band/modulation type" including e.g. power,
DVB-S2X, GSC and modem RSSI
Satellite acquisition Automatic - with and without Gyro/GPS Compass input.
Support for gyro free operation.
Elevation Range -20° to +128°
Cross Elevation +/-42°
Azimuth Range Unlimited (Rotary Joint)
Ship motion, angular Roll ±30° (6 sec), Pitch ±15° (5 sec), Yaw ±10° (8 sec)
Ship, turning rate and
acceleration
15°/s and 15°/s2
ADU motion, linear Linear accelerations +/-2.5 g max any direction
Vibration, operational Sine: EN 60945 (8.7.2), DNV 2.4A, MIL-STD-167-1 (5.1.3.3.5).
Random: Maritime
Vibration, survival Sine: EN 60945 (8.7.2) dwell, MIL-STD-167-1 (5.1.3.3.5) dwell.
Random: EN60721-3-6 class 6M3 mod. by EN60721-4-6
Shock EN60721-3-6 class 6M3 mod. by EN60721-4-6.
MIL-STD-810F 516.5 (Proc. II)
Temperature (ambient) Operational: -25°C to +55°C / -13°F to +131°F
Storage: -40°C to +85°C / -40°F to +185°F
Humidity 95%, condensing
Rain / IP class EN 60945 Exposed / IPx6
Wind 80 knots operational / 110 knots Survival
Ice, survival 25 mm
Solar radiation 1120 W/m2 to MIL-STD-810F 505.4
Compass safe distance 1.5 m / 59" (EN 60945)
Maintenance, scheduled None
Maintenance, unscheduled All modules, motor, RF parts and belts are replaceable
Built In Test Power On Self-Test, Person Activated Self-Test and
Continuous Monitoring w. error logging
Dimensions (eDome)
a
Height: H 92 cm / 36.2"
Diameter: Ø 84 cm / 33.1"
Weight
a
44 kg / 97 lb
a. Specifications may vary for earlier variants, refer to Specifications, earlier variants of SAILOR
600 XTR GX-R2 on page A-8
Table A-2: SAILOR 600 XTR GX-R2 (4.5 W) specifications (Continued)
