COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix A: Technical specifications A-8
Specifications SAILOR 600 XTR GX-R2
A.2.1 Specifications, earlier variants of SAILOR 600 XTR GX-R2
If you have an earlier variant of SAILOR 600 XTR GX-R2 ADU, some specifications vary
slightly from the values in the previous section. Refer to the following tables for these
specifications. The first is for variants with carbon pedestal and composite radome:
P/N 407506A-00540 SAILOR 600 XTR GX-R2 ADU (4.5W) and
P/N 407506D-00540 SAILOR 600 XTR GX-R2 ADU (9W).
Table A-3: SAILOR 600 XTR GX-R2, specifications with carbon pedestal and composite radome
www.cobhamsatcom.com
SAILOR XTR BELOW DECK UNIT (BDU)
Dimensions 1U 19 in. rack mount
HxWxD: 4.4 x 48 x 33 cm / 1.
73 x 18.9 x 13 in.
Weight 3.6 kg / 8 lb
Temperature (ambient) Operational: -25°C to +55°C / -13°F to +131°F
Storage: -40°C to +85°C / -40°F to +185°F
Humidity EN 60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 30cm / 12 in. to IEC EN 60945
,QWHUIDFHV [0DOH1&RQQHFWRUIRUDQWHQQD5)&DEOH 
with automatic cable loss compensation.
[)&RQQHFWRUVƻIRU5[DQG7[WR96$7PRGHP
1 x Ethernet Data (VSAT Modem Control)
2 x Ethernet (User)
1 x Ethernet (Remote access)
 [(WKHUQHWIRU6HUYLFHDQG&RQ¿JXUDWLRQ
1 x RJ-45, RS-422 Data (VSAT Modem Control)
1 x RJ-45, RS-232 Data (VSAT Modem Control)
1 x RJ-45, NMEA 0183 (RS-422 / RS-232) for Gyro/
GPS Compass and external GPS input
1 x RJ-45, 4 x General purpose GPIO, Tx mute and Rx lock.
1 x AC Power Input
1 x Grounding bolt
User Interface Webserver, OLED display (red), 5 pushbuttons, 3
 GLVFUHWHLQGLFDWRU/('VDQG2Q2໤VZLWFK7;0XWH 
and Modem Lock indicator.
Temperature control Built-in fan
No transmit zones Programmable, 8 zones with azimuth and elevation
Real-time blocking map recorder
Remote management and IoT HTTPS, SSH, Telnet, SNMP Traps, Syslog, CLI,
Diagnostic, Statistic, RESTful, MQTT
VSAT MODEM SUPPORT
Modem protocols Generic, OpenAMIP, OpenBMIP, Custom protocol
Modem har
dware iDir
ect SMB3315 Satellite Modem Board
7523A - SAILOR GX-R2 MODEM UNIT (GMU2)
Dimensions 1U 19in. Rack Mount
HxWxD: 4.4 x 48 x 33 cm / 1.
73 x 18.9 x 13 in.
Weight 2.7 kg / 6 lb
Humidity IEC EN 60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 40cm / 16 in. to IEC EN 60945
,QWHUIDFHV [60$FRQQHFWRUVƻIRU5[DQG7[WR%'8
1 x SMA-connector (RX2, not used)
1 x SMA-connector (Ref., not used)
2 x power (DC loop back)
4 x RJ-45 Ethernet (modem control and user data)
1 x RJ-45 & D89 - RS-422 (modem control)
1 x RJ-45 + D89: RS-232C Data (modem control)
1 x Universal AC Power input
Grounding 1 x grounding bolt
Input power 100 – 240 VAC, 50-60 Hz, 90 W peak, 30 W typical
Modem interface (control) LAN, RS-422, RS-232C
'LVSOD\ :HE00,2Q2໤VZLWFKDQGSRZHUVWDWXV/('V
Temperature control Built-in fan
SYSTEM SPECIFICATIONS
5HÀHFWRUVL]H FPLQ
T
ype appro
vals Inmarsat
&HUWL¿FDWLRQ &RPSOLDQWZLWK&(0DULWLPH(76,)&&
System power supply range 100-240 VAC, 50-60 Hz
System power consumption 4.5W: 135 W typical, 185 W max (excl. Modem)
9.0W: 180 W typical, 215 W max (excl. Modem)
FREQUENCY BAND: Ka-band (Inmarsat GX
-R2)
Rx 17.
7 to 20.2 GHz
Tx 27.5 to 30.0 GHz
ANTENNA CABLE & CONNECTORS
%'8WR$'8FDEOH &RD[FDEOHI
RU5[7[0R&$DQG'&SRZHURQ
a single cable
$'8FDEOHFRQQHFWRU )
HPDOH1&RQQHFWRUƻ
%'8FDEOHFRQQHFWRU )HPDOH1&RQQHFWRUƻ
SAILOR XTR AB
OVE DECK
UNIT (ADU)
Antenna type, pedestal 3-axis stabilized tracking antenna with integrated
GNSS supporting GPS
, GLONASS and Beidou
$QWHQQDW\SHUHÀHFWRUV\VWHP 5HÀHFWRUVXEUHÀHFWRUULQJIRFXV
Transmit Gain 43.6 dBi typ. @ 29.5 GHz (Incl. radome)
Receive Gain 39.1 dBi typ. @ 19.7 GHz (Incl. radome)
6\VWHP*7 G%.W\S#*+]DWHOHYDWLRQDQG 
clear sky (incl. radome)
GX-R2 transceiver output 4.5W or 9.0W
EIRP 4.5W: 50.1 dBW typ. @ 29.5 GHz (incl. radome)
9.0W: 53.1 dBW typ. @ 29.5 GHz (incl. radome)
LNB Inmarsat GX-R2 transceiver
Polarisation
Circular (RHCP, LHCP) independent controlled for Rx & Tx
Tracking receiver Internal “all band/modulation type” including e.g.
power, DVB-S2X, GSC and modem RSSI
Satellite acquisition Automatic - with and without Gyro/GPS Compass
input. Support for gyro free operation.
Elevation Range -20° to +128°
Cross Elevation -42° to +42°
Azimuth Range Unlimited (Rotary Joint)
Ship motion, angular
Roll ±30° (6 sec), Pitch ±15° (5 sec), Yaw ±10° (8 sec)
Ship, turning rate and acceleration 15°/s and 15°/s2
ADU motion, linear Linear accelerations +/-2.5 g max any direction
Vibration, operational Sine: EN 60945 (8.7.2), DNV 2.4A, MIL-STD-167-1
(5.1.3.3.5). Random: Maritime
Vibration, survival Sine: EN 60945 (8.7.2) dwell, MIL-STD-167-1
(5.1.3.3.5) dwell.
Random: EN60721-3-6 class 6M3 mod. by EN60721-4-6
Shock EN60721-3-6 class 6M3 mod. by EN60721-4-6.
MIL-STD-810F 516.5 (Proc. II),
Temperature (ambient) Operational: -25°C to +55°C / -13°F to +131°F
Storage: -40°C to +85°C / -40°F to +185°F
Humidity 95%, condensing
Rain / IP class IEC EN 60945 Exposed / IPx6
Wind 80 knots operational / 110 knots Survival
Ice, survival 25 mm / 1 in.
Solar radiation 1120 W/m2 to MIL-STD-810F 505.4
Compass safe distance 1.5 m / 59 in. (IEC EN 60945)
Maintenance, scheduled None
Maintenance, unscheduled All modules, motor, RF parts and belts are replaceable
Built In Test Power On Self-Test, Person Activated Self-Test and
Continuous Monitoring w. error logging
Dimensions (over all) Height: H 91 cm / 36 in.
Diameter: Ø 82 cm / 32 in.
Weight 35 kg / 77 lb
71-178146-A05 03.23
