98-175666-D Appendix A: Technical specifications A-12
Patents
A.4.1 Specifications SAILOR GX Modem Unit 7023A
A.5 Patents
The patents listed below apply to SAILOR XTR
7023A - SAILOR GX MODEM UNIT
Modem hardware CX751 iDirect Core Module
Modem protocols Generic, OpenAMIP, OpenBMIP, Custom protocol
Dimensions 1U 19” Rack Mount
HxWxD: 4.4 x 48 x 33 cm/ 1.73” x 19” x 13”
Weight 3.5 kg / 7.7 lb
Humidity EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.4 m / 16”
Interfaces 8 x RJ-45 Ethernet for modem control and user data
2 x F connectors (75 Ohm) for Rx and Tx to BDU
1 x F-connector (not used)
1 x DB9 connector, RS-422 (Modem Control)
1 x DB9 connector, RS-232 (Modem Control)
1 x I/O connector for Tx Mute and Rx Lock
1 x Universal AC power input
1 x Ground stud with wing nut
Modem interface control LAN, RS-422 and RS-232
Input power 100-240 VAC, 50-60 Hz, 90 W peak, 30 W typical
User interface Web interface, On/Off switch and Status & Power LED
Temperature control Built-in fan and heater
Table A-8: 7023A GMU specifications
Patent application number Description
11749202.5; 10-2013-7008607;
13/819,621
An assembly comprising a movable and
brakable/dampable part and a method for braking a
movable part
PCT/EP2012/063849 Combined antennas without switch
Table A-9: Patents
