98-175666-D Appendix B: Dual antenna solution B-4

Configuration of the dual antenna solution

B.3 Configuration of the dual antenna solution

B.3.1 Overview

The master antenna VSAT profile is configured the same way as a single antenna

system. The master is additionally enabled to be a dual antenna master system and

will always listen for a slave connection. The slave antenna initiates the master/slave

connection. When master has connectivity to a slave, it will forward satellite pointing

data to the slave. If the master loses connection to the slave it will continue in stand-

alone operation. The following list shows the tasks for setting up a dual-antenna

system:

• To configure the Master BDU

• To configure the Slave BDU

• Blocking zone setup for dual antenna setup

• To make an OTC for dual antenna systems

10 Slave BDU Rx in to RX splitter in Rx when slave is active

11 GMU Rx in to RX splitter out Rx from GMU

Cable Connection Purpose

Table B-1: Dual mode antenna, cabling (Continued)
