COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix A: Technical specifications A-5
Specifications SAILOR 1000 XTR GX-R2
A.1.1 Specifications, SAILOR 1000 XTR GX-R2 w. Composite radome
If you have a SAILOR 1000 XTR GX-R2 with Composite radome, some specifications
may vary slightly from the values in the previous section. Refer to the table below for
specifications for these antennas, P/N 407509C-00540 SAILOR 1000 XTR GX-R2 ADU
(4.5W) or P/N 407509D-00540 SAILOR 1000 XTR GX-R2 ADU (9W).
www.cobhamsatcom.com
SAILOR XTR BELOW-DECK UNIT (BDU)
Dimensions 1U 19 in. Rack Mount
HxWxD: 4.4 x 48 x 33 cm / 1.
75 x 19 x 13 in.
Weight 3.6 kg / 8 lb
Temperature (ambient) Operational: -25ºC to +55ºC / -13°F to +131°F
Storage: -40ºC to +85ºC / -40°F to +185°F
Humidity EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 30cm / 12 in. to IEC EN 60945
,QWHUIDFHV [1&RQQHFWRUIRUDQWHQQD5)&DEOHƻ 
with automatic cable loss compensation
 [)&RQQHFWRUVƻIRU5[7[WR96$7 
modem
1 x Ethernet Data (VSAT Modem Control)
2 x Ethernet (User)
1 x Ethernet (Remote access)
 [(WKHUQHWIRU6HUYLFHDQG&RQ¿JXUDWLRQ
1 x RJ-45, RS-422 Data (VSAT Modem Control)
1 x RJ-45, RS-232 Data (VSAT Modem Control)
1 x RJ-45, NMEA 0183 (RS-422 / RS-232) for
Gyro/GPS Compass and external GPS input
1 x RJ-45, 4 x General purpose GPIO, Tx mute
and Rx lock.
1 x Universal AC power input
1 x Grounding bolt
User interface Webserver, OLED display (red), 5 pushbuttons,
 GLVFUHWHLQGLFDWRU/('VDQG2Q2໤VZLWFK7;
Mute and Modem Lock indicator
Temperature control Built-in fan
No transmit zones
Programmable, 8 zones with azimuth and elevation
Real-time blocking map recorder
Remote management and IoT HTTPS, SSH, Telnet, SNMP Traps, Syslog, CLI,
Diagnostic, Statistic, RESTful, MQTT
VSAT MODEM SUPPORT
Modem protocols Generic, OpenAMIP, OpenBMIP, SNMP
Modem har
dware iDir
ect SMB3315 Satellite Modem Board
7523A - SAILOR GX-R2 MODEM UNIT (GMU2)
Dimensions 1U 19 in. Rack Mount
HxWxD: 4.4 x 48 x 33 cm / 1.
75 x 19 x 13 in.
Weight 2.7 kg / 6 lb
Humidity IEC EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 40 cm / 16 in. to IEC EN 60945
,QWHUIDFHV [60$FRQQHFWRUVIRU5[7[WR%'8
1 x SMA-conncector (RX2, not used)
1 x SMA-conncector (Ref., not used)
2 x power (DC loop back)
4 x RJ-45 Ethernet: modem control + user data
1 x RJ-45 + D89: RS-422 (modem control)
1 x RJ-45 + D89: RS-232 Data (modem control)
1 x Universal AC power input
Grounding 1 x grounding bolt
Input power
100-240 VAC, 50-60 Hz, 90 W peak, 30 W typical
Modem interfaces LAN, RS-422, RS-232C
8VHULQWHUIDFH :HE00,2Q2໤VZLWFKSRZHUVWDWXV/('V
Temperature control Built-in fan
SPECIFICATIONS
5
HÀHFWRUVL]H FPLQ
Type appr
ovals Inmarsat
&HUWL¿FDWLRQ &RPSOLDQWZLWK&(0DULWLPH(76,)&&
System power supply range 100-240 VAC, 50-60 Hz
Antenna system power 4.5W: 135W typ. 185W max.
consumption 9.0W: 180W typ. 215W max.
FREQUENCY BAND: K
a-Band (I
nmarsat GX-R2)
Rx 17.7 to 20.2 GHz
Tx 27.5 to 30.0 GHz
ANTENNA CABLE
%'8WR$'8FDEOH &RD[FDEOHI
RU5[7[0R&$DQG'& 
power on a single cable
$'8FDEOHFRQQHFWRU )HPDOH1&RQQHFWRUƻ
%'8FDEOHFRQQHFWRU )
HPDOH1&RQQHFWRUƻ
SAILOR XTR AB
OVE DECK
UNIT (ADU)
Antenna type, pedestal 3-axis stabilized tracking antenna with
integrated GNSS supporting GPS, GLONASS and
Beidou
5DGRPHWRSPDWHULDO *ODVV¿EHUUHLQIRUFHGSODVWLF
$QWHQQDW\SHUHÀHFWRUV\VWHP 5HÀHFWRUVXEUHÀHFWRUULQJIRFXV
Transmit Gain 48.3 dBi typ. @ 29.5 GHz (incl. radome)
Receive Gain 43.9 dBi typ. @ 19.7 GHz (incl. radome)
6\VWHP*7 G%.W\S#*+]DWHOHYDWLRQ
and clear sky (incl. radome)
Ka-band transceiver output power 4.5 Watt or 9 Watt
(,53 :G%:LQFOUDGRPH
 :G%:LQFOUDGRPH
LNB Ka-band transceiver (“XCVR”)
Polarisation Circular (RHCP, LHCP), controlled for Rx and Tx
Tracking Receiver Internal “all band/modulation type” including
e.g. power, DVB-S2X, GSC and modem RSSI
Satellite acquisition Automatic - with Gyro/GPS Compass input. Sup
port for gyro free operation.
Elevation Range -20° to +120°
Cross Elevation -37° to +37°
Azimuth range Unlimited (rotary joint)
Ship motion, angular Roll ±30° (6 sec), Pitch ±15° (5 sec),
Yaw ±10° (8 sec)
Ship, turning rate and acceleration 15°/S and 15°/S2
ADU motion, linear Linear accelerations ±2.5 g max any direction
Vibration, operational Sine: EN60945 (8.7.2), DNV 2.4A, MIL-
STD-167-1 (5.1.3.3.5). Random: Maritime
Vibration, survival Sine: EN60945 (8.7.2) dwell, MIL-STD-167-1
(5.1.3.3.5) dwell. Random: EN60721-3-6 class
6M3 mod. by EN60721-4-6. Shock: EN60721-3-
6 class 6M3 mod. by EN60721-4-6.
MIL-STD-810F 516.5 (Proc. II)
Temperature (ambient) Operational: -25°C to +55°C / -13°F to +131°F
Storage: -40°C to +85°C / -40°F to +185°F
With SAILOR Smart heater option: Operational: -55°C to +55°C / -67°F to +131°F
Humidity 95%, condensing
Rain / IP class EN60945 Exposed / IPx6
Wind 80 knots operational, 110 knots survival
Ice, survival 25 mm / 1 in.
Solar radiation 1120 W/m2 to MIL-STD-810F 505.4
Compass safe distance 1.5 m / 59 in. to IEC EN 60945
Maintenance, scheduled None
Maintenance, unscheduled All modules, motor, RF parts and belts are
replaceable through service hatch
Built In Tests Power On Self-Test, Person Activated Self-Test
and Continuous Monitoring w. error logging
Dimensions Height: H 150 cm / 58.9 in.
Diameter: Ø 130 cm / 51.3 in.
Weight 105 kg / 231 lb
71-177909-A05 03.23
