COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix F: Event messages F-3
List of events
08076-0 ADM WARNING Dual mode
configuration
The system is configured as a dual
antenna system, but the master and slave
systems are not identical. The dual mode
function may not work properly or
performance could be degraded. Info
code: xxxxxxx1 = Antenna types are
different xxxxxxx2 = Antenna subtypes are
different xxxxxxx3 = Software versions on
master and slave are different xxxxxxx4 =
LNB types are different xxxxxxx5 = BUC
types are different xxxxxxx6 = OEM ids are
different
08077-0 ADM WARNING BUC LO
frequency
invalid
The satellite modem provided an invalid
BUC LO frequency. A default BUC LO
frequency is assumed based on antenna
type. To remove this warning re-configure
the modem to provide a valid BUC LO
frequency.
08078-0 ADM WARNING VMU TX
frequency
invalid
The satellite modem did not provide a Tx
frequency, or it is invalid. A default Tx
frequency is assumed, but this may
degrade Tx performance. To remove this
warning re-configure the modem to
provide the correct Tx frequency.
0807A-0 ADM WARNING Automatic
azimuth
calibration
pending
Automatic azimuth calibration mode is
enabled. The system tries to perform an
azimuth calibration using the target
satellite whenever satellite data is
received from the modem. After
successful calibration the feature is
automatically disabled and the system
returns to normal operation. WARNING: If
a system has not completed azimuth
calibration after the installation, the
blocking zones may appear to be at
wrong angles.
0807B-0 ADM WARNING OTC required
(Calibration
outdated)
BUC calibration is outdated. Rerun it from
the Core Module by using the One Touch
Commissioning in the web interface.
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
