98-175666-D Appendix F: Event messages F-4
List of events
0807E-0 ADM WARNING Keyline signal The keyline signal on the dual antenna
master does not match the keyline signal
on the slave. Check that the keyline
splitter cable is connected to the RS422
connectors. When fixed, the BDUs need to
be rebooted to clear the event.
0807F-0 ADM WARNING Local
administration
enabled
Local administration mode is currently
enabled. This allows login without
providing the admin password. Will be
disabled after 1 hour or next reboot.
08081-0 ADM WARNING BUC
communication
Missing communication between VMU
and BUC. Info: 0x00000001: From VMU to
BUC Info: 0x00000002: From BUC to VMU
08082-0 ADM WARNING Modem
configuration
load
Unable to load configuration on modem.
Info: 0x00000001: Configuration index
invalid 0x00000002: Changing
parameter not permitted 0x00000004:
Modem not in Remote Mode
08083-0 ADM WARNING Vsat Modem
network
settings
VSAT Profile activation issue: Modem LAN
port settings rejected.
08084-0 ADM WARNING Radome fan
blocked/not
rotating
Radome fan is blocked or not rotating
even if it should.
08085-0 ADM INFO Radome temp
too high
The temperature in the radome is too
high.
08086-0 ADM WARNING GPIO Tx mute
active
Tx has been muted from GPIO on the
BDU.
08087-0 ADM WARNING Temperature
protection
Temperature too high. BUC shut down.
08088-0 ADM WARNING Antenna data
not
synchronised
Persistent antenna data not synchronized
in all backup locations. Retry will happen
on next boot. Info code shows sum of all
outdated copies Info: 0x00000002 ISCM
0x00000004 Azimuth IFDM 0x00000008
Cross elevation IFDM 0x00000010
Elevation IFDM 0x00000020
Polarisation IFDM
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
