COBHAM Satcom SAILOR XTR GX-R2 User Manual

98-175666-D Appendix F: Event messages F-15
List of events
0B0A1-0 APSM ERROR BDCM
Communication
error
No communication with BDCM. Check
main antenna cable.
0D000-0 BDCM WARNING BDU PSU
temperature too
high
BDU PSU temperature too high.
0D001-0 BDCM WARNING BDU PSU fan
does not work
BDU PSU fan does not work.
0D002-0 BDCM ERROR BDU PSU will
shutdown
BDU PSU will shutdown.
0D003-0 BDCM ERROR BDCM prod data BDCM prod data is invalid.
0E000-0 AIMO ERROR AIM-O
Communication
Startup of communication with AIM-O
failed.
0E001-0 AIMO ERROR AIM-O PLL out of
lock
PLL out of lock.
0E002-0 AIMO ERROR AIM-O voltage
range
Voltage measured at AIM-O is not within
expected range.
0E003-0 AIMO ERROR AIM-O cal data AIM-O calibration data is invalid.
0F000-0 BIMO ERROR BIM-O
Communication
Startup of communication with BIM-O
failed.
0F001-0 BIMO ERROR BIM-O PLL out of
lock
PLL out of lock.
0F002-0 BIMO ERROR BIM-O voltage
range
Voltage measured at BIM-O is not within
expected range.
0F003-0 BIMO ERROR BIM-O cal data BIM-O calibration data is invalid.
0F004-0 BIMO WARNING VMU reference
signal
There is no VMU Rx or Tx reference signal.
Whether this is Rx or Tx reference
depends on the user's selection on the
modem profile page in the web interface.
Make sure the VMU Rx/Tx cable is
connected and that the VMU is configured
to output the RX/TX reference signal.
0F005-0 BIMO WARNING No BIMO Master
PLL
BIMO Master PLL out of lock.
0F006-0 BIMO WARNING No BIMO LO PLL BIMO LO PLL out of lock.
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
