8CH 1080P SECURITY CAMERA SYSTEMPRODUCT OVERVIEW
DVR Rear Panel
1. Video In (BNC)
2. Audio Out (RCA)
3. LAN/Network Por
4. 12V Socket
5. Audio In (RCA)
6. HDMI Por
7. USB Pors
Product Overview
DVR Front and Side Panel
1. Power Indicator
2. LAN Indicator
3. HDD Indicator
4. USB Por
1 3
2
4
1
2
5
3
6
4
7
