After Sales Support
help@cocoonproducts.com.au
Model number:
HE210303
02/2022
8CH 1080P SECURITY CAMERA SYSTEMDVR OPERATION
Quick Pop-up Menu
Right-clicking the mouse whilst on the viewing screen will show the pop-up menu for
quick access to basic functions.
• Single – Switch to single camera view mode. Select the camera you want to view
• Multi – Switch to split screen mode
TIP: Alternatively, use the mouse and double click with LMB on the image to switch between
the two modes
• Star/Stop Scan – This will show each camera in single view and at selected intervals
switch between each camera automatically
• Colour – Adjust the colour settings of the selected camera
• E-Zoom – Select an area on the camera screen to get a close up view. You can also
select the size in which you want to zoom to by selecting the numbers in the bottom
right corner of the screen. Right-click to return to full screen mode
• Audio – Audio settings. Must have Audio input and output devices (not included)
installed and connected
• Snap – Take a photo from the selected camera (a camera icon will show up indicating a
photo has been taken). To access photos, see “Main Menu - Search” on page 28
• Star/Stop Record – Star and Stop 24/7 recording all cameras (default settings). In
the bottom le corner of each camera view, you will notice a green box, this means the
cameras are recording. If there is no green box they are not recording.
NOTE: If footage is captured by motion detection (see “Schedule” on page 24), a yellow
square and ‘MD’ will appear instead
• Playback – Enter playback mode to view recently recorded footage
• Main Menu – Access the main menu to conigure DVR settings
Once you have set your username and password, your Security System is fully setup.
To setup and view your cameras on mobile see “Use Apple or Android mobile to access
footage” on page 16 or for PC see “Cocoon HD Soware for PC Use” on page 19.
