8CH 1080P SECURITY CAMERA SYSTEMADVANCED SETTINGS
Network
Network tab
Conigure your network settings here:
• HTTP Por: Default value is 80
• Server Por: Default value is 5000
• Mobile Por: Default value is 5001
• Obtain an IP Address Automatically: To obtain the IP function automatically (we
recommend leaving this box ticked)
• IP Address: To set the IP address of the device
• Subnet Mask: To set the subnet mask of the device
• Gateway: To set the default gateway of the DVR
• Preferred DNS Server: This address is provided automatically by your network
operator and must be illed in when using mobile monitoring
• Alternate DNS Server: This address is provided automatically by your network
operator
• PPPOE: When enabled, the DVR will automatically establish a network connection in
the form of PPPOE, then the IP address can be seen through Main Menu Information
Network
• Username: For PPPOE mode, enter the ISP (Internet Service Provider)
• Password: For PPPOE mode, set password
• Test: Check whether the entered IP address and PPPOE information are valid or not
Email tab
The Cocoon HD Security System can email you motion alers if settings are enabled.
Contact your network administrator if you do not have this information. We recommend
using a webmail service such as Gmail, Yahoo etc
• SMTP Server: Enter your server details. e.g.: smtp.gmail.com
• Por: Enter your SMTP por number
• SSL Check: Enable if your server uses SSL
• Send Address: Email address notiications sent from
• Password: Email Password
• Receive Address: Email address the alers will be send to
• Test: Check whether the entered SMTP information is valid or not
