Preparing the transceiver for use
24 Manpack Transceiver 2110 series Getting Started Guide
To charge a battery pack:
1 Do one of the following:
• For a 2110 Manpack Transceiver with the battery pack
attached to the transceiver, use cable 08-06215-001 to
connect the output from the 3121, 3122, solar or hand-
powered battery charger to the 19-way connector on
the front panel of the transceiver.
• For a 2110v Manpack Transceiver with the battery
pack attached to the transceiver, use cable
08-06738-001 to connect the output from the 3121,
3122, solar or hand-powered battery charger to the
5-way connector on the front panel of the transceiver.
• If the battery pack is detached from the transceiver, use
cable 08-06214-001 to connect the output from any of
the Codan battery chargers to the 6-way connector on
the top of the battery pack.
1 Connect the charger to an appropriate power source.
NOTE
If the voltage of the battery pack is below 10 V,
the OUTPUT LED on the 3121 and 3122
chargers will flash orange for a period of time
before charging commences. The LED may
also flash during this period.
NOTE
The 3123 Fast AC Battery Charger
cannot be used to charge a battery pack
via the front panel of the transceiver.
NOTE
If you are using a solar battery charger,
ensure that the panel is oriented at right
angles to the rays of the sun.
NOTE
If you are using a hand-powered battery
charger, strap it to a tree, or attach it to the
stand provided using the wingnuts.
