Maintenance and fault finding
90
Block Up Converter Systems 6700/6900 series User Guide
Figure
19:
BUC fault diagnosis chart
4
BUC fault
diagnosis chart 4
Is PA
OK?
Is
FLT
LED
red and PA
showing a
fault?
See BUC fault
diagnosis chart 5.
Switch off BUC PA
using
STO0
command.
Reset BUC using
RST
command. Reset
latched faults using
RLF
command.
Switch on BUC PA
using
STO1
command.
BUC faulty.
Refer to Codan.
BUC OK.
Monitor for recurrence
of fault.
No
No
Yes
Yes
99
101
