Switches
The control panel of the redundancy controller has one switch.
The function of this switch is to select the AC input voltage
(115 or 230 V AC).
Connectors
The connector panel is located at the bottom of the
redundancy controller.
Figure 10: Connector panel on the redundancy
controller
BUC Switch Control
LNB Switch Control
BUC 2 Serial
BUC 1 Serial BUC 1 Control
BUC 2 Control
AC Power Input
Auxiliary I/O
Rx IF Input 2Rx IF OutputRx IF Input 1Tx IF Output 2Tx IF InputTx IF Output 1
