Block Up Converter Systems 6700/6900 series User Guide 115
CODAN
Appendix B—Example outputs
for the View commands
View system status
The figures in brackets are the parameter values enabled for
the Set commands that were used to achieve the settings
displayed.
View operational data
NOTE
These outputs show example data only. The data
displayed can vary between BUC systems and
firmware versions.
NOTE
In a system without redundancy:
• the BUC is always On Line; this setting
cannot be changed
• the Redundant Mode must always be set to
non-redundant (0)
-----------------------System Status-------------------------------
PA State Off Transmit Atten 4
Transmit On (RS232) On (1) Tx Alarm Thresh 0.0
Transmit On (RS485) Off (0) Burst Pwr Thresh 19.0
Transmit On (FSK) On (1) Serial I/face 9600,8,N,1,T
Transmit Default Off (0) Packet Protocol Codan (1)
Compensation Freq 0 Packet Address 126
IF Comp Freq 0 Red'cy -Mode Non (0)
LO Freq 7375 -On/Off Line On (1)
-----------------------------------------------------------------
---------------------Operational Data----------------------
Output Power 0.0 Burst Power 0.0
Min Burst Power 0.0 Max Burst Power 99.9
Temperature(C) 31
----------------------------------------------------------
