Maintenance and fault finding
Block Up Converter Systems 6700/6900 series User Guide 83
Fuses and overcurrent protection in the Redundancy
Controller 6586
Table 18 lists the types of fuses on the control panel of the
redundancy controller and the device protected. For
information on changing fuses see page 102, Replacing fuses
in the redundancy controller.
Table 18: Fuses in the redundancy controller
Label Type Protects...
BUC 1/BUC 2 Delay 20 × 5 mm, 5 A BUC 1/BUC 2
LNB 1/LNB 2 Delay 20 × 5 mm, 1 A LNB 1/LNB 2
Remote Controller Delay 20 × 5 mm, 250 mA Remote Controller 6570
NOTE
LNB fuses are fitted, but are not used in
transmit-only systems.
