Overview
Block Up Converter Systems 6700/6900 series User Guide 15
LNB
The frequency band that is down converted by the LNB is
indicated on the model label of the LNB.
C-Band
The C-Band LNB is supplied for operation on the frequency
band 3400 to 4200 MHz. It has an LO frequency of
5150 MHz.
Ku-Band
The Ku-Band LNB may be supplied for operation in one of
three frequency band options listed in Table 7.
NOTE The C-Band LNB is frequency inverting.
Table 7: Frequency band options for the Ku-Band LNB
Band option Receive frequency
(MHz)
LO frequency
(MHz)
L-Band output
frequency
(MHz)
1 10950–11700 10000 950–1700
2 11700–12200 10750 950–1450
3 12250–12750 11300 950–1450
