Maintenance and fault finding
88
Block Up Converter Systems 6700/6900 series User Guide
Figure
17:
BUC fault diagnosis chart
2
BUC fault
diagnosis chart 2
Is
Tx Power
Alarm
OK?
Check the IF level
(Test D)* and the
output power alarm
threshold and adjust
as required.
Is
BUC Temp
OK?
Check faults using
VFS
command.
Does
BUC have
a fan?
See BUC
fault
diagnosis chart 3.
See BUC fault
diagnosis chart 4.
* Refer to test
procedures
Reset latched
faults using
RLF
command.
Wait for BUC to cool
down. Ensure air flow
around BUC is not
restricted.
No
Yes
No
Yes
Yes
No
97
99
