Setting up and operating the BUC system
Block Up Converter Systems 6700/6900 series User Guide 61
Redundancy
Controller Status
green Redundancy system and switches are OK
red Redundancy system is faulty or switches are
inconsistent
Remote
Controller fuse
green Remote controller fuse OK
red Remote controller fuse has blown
BUC 1/BUC 2
fuse
green BUC 1 or BUC 2 fuse is OK
red BUC 1 or BUC 2 fuse has blown
LNB 1/LNB 2 fuse green LNB 1 or LNB 2 fuse is OK
red LNB 1 or LNB 2 fuse has blown
NOTE
The LNB 1, LNB 2 and LNB Switch LEDs
are fitted, but not operational in transmit-only
systems.
Table 12: LED indicators on the control panel of the
redundancy controller (cont.)
LED Colour Indicates...
