ENVOY™ TRANSCEIVER GETTING STARTED GUIDE 77
6
Specifications
Table 3: Specifications
Item Specification
Frequency range Transmit: 1.6 to 30 MHz
Receive: 0.25 to 30 MHz
Channel capacity
(single or two-frequency
simplex channels)
X1: 100
X2: 1000
Operating modes Single sideband (J3E) USB and LSB or switched
USB/LSB, AM (A3E Rx, H3E Tx), CW (J1A, A1A)
Environment Ambient temperature: −30 to +60°C
(–22 to 140°F)
Relative humidity: 95%
Derate upper ambient temperature by 1°C (33.8°F) per
330 m (360 yd) above sea level
Cooling Convection or fan (Option F)
