To remove the battery, push the battery compartment latch in the direction indicated by
the arrow (Figure 6) until the battery pops up slightly. Pull the battery out of the reader
cavity.
5.7. Connecting Charging Station
Use only cables or power supply provided by Code to ensure proper communication with
the host and to provide adequate voltage to charge the reader.
5.7.1. Insert the micro USB connector of the cable to the micro USB port on the bottom
of the charging station (Figure 7)
5.7.2. Run the cable along the cable routing guides on the bottom of the charging
station. If the charging station will be placed into a desktop base (CRA-MB6), the
cable should exit through the opening in the back of the charging station (see
Figure 8). If the charging station will be mounted on a wall mount bracket (CRA-
WMB4) or a VESA mount bracket (CRA-MB7), thread the cable through one of the
two cable exit holes on the bracket (see Figure 9 or 10)
Please note, the CRA-A271 may not charge consistently or at all when connected to
a USB hub, even if the hub is powered.
Figure 7 Connect Charging Station
