6.2. Targeting
The CR2700 reader emits a blue targeting bar to help capture the barcode within its field of
view (Figure 13). For best performance, aim at the barcode with the targeting bar.
6.3. Presentation Scanning
The CR2700 supports presentation scanning in the charging station. This enables scanning
without pressing a scan button or pulling the trigger. This feature is off by default but can
be enabled using an M-Code from the Configuration Code Generator on Code’s website or a
command sent via the software tool CortexTools2 (see section 8.2). If this feature is
enabled and the reader is placed into a wall mounted or cart mounted charging station, the
reader enters presentation scanning mode. When an object is presented in its field of view,
the reader will automatically emit red illumination, turn on the targeting bar, and attempt
to scan barcodes (Figure 14). A successful read will be indicated by a beep and flashing
green in the indicator window. Normal reading distance is about 10 cm (4”) from the
window of the reader or 9 cm (3.5”) from the bottom of the base but the user may need to
move the barcode closer or farther away for best results depending on barcode size.
Figure 14 Presentation Scanning
