Code CR2700 - 13. CR2700 Device Information; Reader Information Retrieval

38
13. CR2700 Device Information
13.1. Reader Information
For device management and obtaining support from Code, reader information will be
needed. To find out the reader model number, serial number, firmware version and
optional licenses, run CortexTools2 software, connect the reader to the PC via the Bluetooth
charger A271. Once CortexTools2 indicates the reader is connected, go to the Advanced
tab. Scan the barcode below (M20361).
Following data will be displayed:
Device Model Number
Serial Number
Firmware Version Number
License Information (if installed)
Bluetooth Device Name (may be changed by user)
Custom Date (if embedded by user)
