CODEL Tunnel Tech 700 Series User Manual

Technical Manual CODEL
55
8.4.3. Validity State: Allows user to set up the Validity state in case of data
invalid situation. The following are the sub menus.
 Validity State
 Set Validity State
 Use or to scroll through to Validity state submenu.
8.4.3.1. Set Validity State: Allows user to set the Validity state.
 Press to access Set Validity State sub menu.
 Validity States Options in case of data invalid
condition.
Zero – measures 4 milliamps.
Simulated – reads the simulated milliamp reading.
Measured – measures milliamps.
Hold Value – Holds the milliamps reading.
Full Scale – reads full scale.
 Use or through the different validity state
options and press to exit.
8.4.4. Smoothing Coeff: Allows user to set up Smoothing Coefficient. The
following are the submenus.
 Smoothing Coeff
 Smoothing Coeff
 Use or to scroll through to Smoothing Coefficient
submenu.
8.4.4.1. Smoothing Coeff: Allows users to set Smoothing Coeff.
 Press to access smoothing coeff sub menu.
Validity State:
Measured
Set Validity Sta
Measured
Set Validity Sta
Full Scale
Validity State:
Full Scale
Smoothing Coeff:
0x000A
Smoothing Coeff:
0x000A
