CODEL Tunnel Tech 700 Series User Manual

Technical Manual CODEL
59
8.4.9. Exit: Allows user to exit to setup mode submenus.
 Use or to scroll through to Exit and press to exit
to Setup mode submenus.
8.5. Relay Output: Allows user to setup Relay output configuration. The following
are the submenus.
 Relay Output
 Abs Location
 Smoothing Coeff
 Direction
 Level
 Data Type
 Use or to scroll through to relay output submenu.
 Press to access Relay output sub menus.
8.5.1. Abs Location: Allows user to set up the absolute data location for relay
output configuration. It has the following submenu.
 Abs Location
 Set Abs Location
 Use or to scroll through to Abs Location submenu.
8.5.1.1. Set Abs Location: Allows users to set the absolute data location.
 Press to access and Set Abs Location.
 The most significant digit is highlighted use or
to Increment or Decrement in hexadecimal.
EXIT
Enter to Exit
Set Zero:
0x0000
4. Setup Mode:
4.6. Rly Outputs
Abs Location:
0x1F6
Abs Location:
0x1F6
Set Abs Location
0x1F6
Set Abs Location
0x 1F6
