Technical Manual CODEL
60
Press to move cursor to next most significant digit.
Repeat above procedure to increment and decrement
and finally press enter to exit Set Abs Location.
8.5.2. Smoothing Coeff: Allows user to set up Smoothing Coefficient. The
following are the sub menus.
Smoothing Coeff
Smoothing Coeff
Use or to scroll through to Smoothing Coefficient
submenu.
8.5.2.1. Smoothing Coeff: Allows users to set Smoothing Coeff.
Press to access and Smoothing Coeff sub menu.
Use or to change the smoothing coefficient in
hexadecimal.
Press to move cursor to next most significant
digit. Repeat above procedure to increment and
decrement and finally press to set smoothing
coefficient and exit.
8.5.3. Direction: Allows user to set up direction of the relay. The following are
the submenus.
Direction.
Set Direction
Use or to scroll through to Direction submenu.
To Next Page
