10-14 Preventive Maintenance
3. Place the receive trays on a flat surface, as shown in the
following figure.
4. Remove any cassettes from the supply slots.
5. Locate the pick tires.
There are three pickers, one for each supply slot. The topmost
picker is shown in the following figure.
Incorrect
Correct
Pick tires
Picker
