Horizon Imager User’s Manual 12-15
7URXEOHVKRRWLQJ
The following figure shows the media path within the imager, and
indicates the lower and upper parts of the imager.
&URVV6HFWLRQRI,PDJHU6KRZLQJ,QWHUQDO0HGLD3DWK
Clearing a jam from these likely locations is described in the
following topics.
Diverter
Ribbon
carriage
Print
head
Pinch
Capstan
Platen
Media
guides
Receive
trays
Cassettes
Hide track
Basement Pickers Pick tiresCassette doors
Upper partLower part
