xxxii Preface
 With the imager top cover open or the receive trays removed,
touch only those internal components that are colored green
(shown in the following figure).
 Remove rings, ties, jewelry, and
other items, and tie back hair, so that they do not fall into or get
caught in the imager.
,QWHUQDO&RPSRQHQWV7KDW$UH&RORUHG*UHHQFDOOHGRXWLQWKH
LOOXVWUDWLRQ$UH6DIHWR7RXFK
Upper fender
releases
(up position)
Top cover releases
Spring-loaded
spindles
Spool wheels
Upper fender
releases
(down position)
Top cover
master
release
Media
guides
Picker
(lift here)
Diverter
