Cognex DataMan 8050 - DataMan 8050 Specifications; DataMan Base Station Specifications

DataMan 8050 Imager Specifications
Specification DataMan
8050
Imager
Image Sensor
1/3 inch CMOS
Image Sensor Properties
6.0 μm square pixels
Image Resolution (Pixels)
752 x 480
DataMan 8050 Specifications
Weight
400 g (with battery)
Operating
Temperature
0ºC — 45ºC (32ºF — 113ºF)
Storage
Temperature
-10ºC — 60ºC (14ºF — 140ºF
Maximum Humidity 95% (non-condensing)
Codes Data Matrix
TM
; QR Code and microQR Code; UPC/EAN/JAN; Codabar,
Interleaved 2 of 5, Code 39, Code 128, and Code 93, Pharma, Postal,
RSS/CS, PDF 417, MicroPDF 417
Power Supply
Requirements
USB: bus powered (optionally: external 2.5W max LPS or NEC class 2
power supply +5V - +6V DC)
RS232 external 2.5W max LPS or NEC class 2 power supply +5V - +6V
DC
ETH: Class 2 PoE supply IEEE 802.3af (connect only to PoE networks
without routing to the outside plant)
Inrush current peak
5A maximum
Duration: approx. 30μs
Electrical charge: 60μAs at 6V
Battery life for
wireless reader
(typical use case)
ca. 3200 triggers can be operated within a 10 hour working shift
Ethernet 10/100 Base-T FULL/HALF DUPLEX, IEEE 802.3
Bluetooth Bluetooth™ 2.1, 2.4 GHz
WiFi 802.11 b/g, 2.4 GHz, User Selectable channels 1-11
DataMan Base Station Specifications
DMA-IBASE-BT-XX DMA-IBASE-01
Weight 300 g 328 g
Operating
Temperature
0ºC — 45ºC (32ºF — 113ºF) 0ºC — 40ºC (32ºF — 104ºF)
Storage
Temperature
-40ºC — 60ºC (-40ºF — 140ºF) -40ºC — 60ºC (-40ºF — 140ºF)
Maximum Humidity 95% (non-condensing) 95% (non-condensing)
Power Supply
Requirements
24V +-10%, 15 W maximum LPS or
NEC class 2 power supply
Recommended wire diameter is
14-18 AWG
24V +- 10%, 13 W maximum LPS or
NEC class 2 power supply, or PoE
class 3 (connect only to PoE
networks without routing to the
outside plant)
13
Setting Up Your DataMan 8050
