Using DataMan 8050 Wireless Readers
This section provides information about the usage of the wireless DataMan 8050 readers. It details the pairing strategy,
the base station routing capabilities, the ad-hoc and infrastructure modes, data buffering as well as how to charge the
DataMan 8050.
Connecting to a Wireless DataMan 8050 Through a Base Station
1. Connect the wireless slide-in (DMCM-BTM-00) to your DataMan 8050.
2. With a 2.5 mm Allen wrench, tighten the screws so that the slide-in is firmly locked.
3. Insert the battery.
Note: Remove the battery from your DataMan 8050 before inserting/removing the communication module.
