Note: The following TruCheck metrics are only available for devices with TruCheck verifier capability,such as the
DM475 Verifier and the DM8072 Verifier.
TruCheckMetric
A graded verification parameter that has a measurement associated with it.
Property Type Description
grade
string The grade of quality in a range from grade A to F, where A is the highest.
raw
float The raw metric.
numericGrade
float The continuous grade value as shown in ISO 15416:2016.
TruCheckMetricGradeOnly
A graded verification parameter that has a measurement associated with it.
Property Type Description
grade
string The grade of quality in a range from grade A to F, where A is the highest.
numericGrade
float The continuous grade value as shown in ISO 15416:2016.
TruCheckApplicationStd
Property Type Description
grade
string The data title for each section of the parsed data.
data
string The raw parsed data.
check
string A Pass/Fail assessment determined by the specific application standard selected.
TruCheckCodeword
Property Type Description
codeword
integer Outputs the codewords associated with the parsed data.
isCorrected
boolean Returns a 0 if the codeword is not corrected using error correction; returns a 1 if the codeword
is corrected using error correction.
TruCheckEncodationAnalysis
Property Type Description
name
string Outputs the codeword for the parsed data.
mode
string Outputs the encodation mode in effect.
result
string Outputs the raw data decoded.
TruCheckMetricGeneral
Property Type Description
contrastUniformity
integer The contrast uniformity value is the minimum modulation of any codeword according
to ISO 15415.
horizontalBWG
integer Print growth in the horizontal axis.
MRD
integer Minimum difference between the brightest bar and the darkest space within the
symbol.
verticalBWG
integer Print growth in the vertical axis.
xDimension
float The normal cell size spacing in mils (thousandths of an inch).
TruCheckMetricModulation
32
DataMan Application Development
