Chapter 4 Setting Delay Values

Setting Delay Values_________________

There are two general methods to set delay values:

 Locally via the MT-100A Microterminal (numeric keypad entry)

 Remotely via the GPIB (IEEE488.2) Interface, the Ethernet TCP/IP Port

interface, or via the Serial Port RS-232 interface.

4.1.0 Working with the MT-100A Microterminal

Make sure the PDL-100A is powered off. Connect the Microterminal to the

instrument. After turning the ON/OFF switch located on the front panel of the

PDL-100A unit, you will hear a short beep indicating that both the MT-100A and

the PDL-100A units have successfully powered up.

The PDL-100A will then perform a self-initialization test and self-calibration.

Upon successfully completing these tests, the Microterminal unit will display:

For Model PDL-100A-625ps (Trombone only):

0.00ps |S| 0

For Model PDL-100A-1.25ns and above (with delay extensions):

0.0000ns |S| 0

The PDL-100A is now ready to accept delay settings.

4.0
