Chapter 4 Setting Delay Values
© 2010 Colby Instruments. PDL-100A Operating and Programming Manual Page 15
4.2.0 Setting Delay with the MT-100A Microterminal
To Enter Desired Delay:
Enter a desired delay setting by using the numeric keypad and pressing ENTER to
set the desired delay.
EXAMPLES:
1. Set delay to 12.50 nanoseconds:
0.5000ns |S|0
Press 12.50 and ENTER sets delay to 12.50 nanoseconds
12.5000ns |S|0
2. Toggle between nanoseconds (ns) or picoseconds (ps) units
12.5000ns |S|0
Press ns/ps toggles units between nanoseconds(ns) or
picoseconds(ps).
12500.00ps |S|0
3. Set delay to 10000 picoseconds
12500.00ps |S|0
10000
Press 10000 and ENTER sets delay to 10000 picoseconds
10000.00ps |S|0
NOTE: After pressing the ENTER key, the PDL-100A will attempt to
set the desired delay and return an error code of zero (0) if the
delay was set properly. A BEEP tone will indicate an error (if any)
and that the desired delay was not set.
