3.1.6 ESC key (9)
The ESC key is used to abort the input of data and to jump back to the previous
branch of the function tree.
3.1.7 UP (13) and DOWN (14) keys
These two keys are used to select a function within a function tree. When entering da-
ta the indicated value can be increased (up key) or reduced (down key) with these
keys.
3.1.8 LABELLING MODE function key (2)
This key is used to select the labelling mode function. When depressed, the LED
placed above lights up and indicates that the monitor is in labelling mode. The Collamat
parameters are entered in this mode. The Figure "LABELLING MODE" menu tree (pa-
ge 11) shows the function tree of the labelling mode.
3.1.9 PROGRAMMING function key (3)
This key is used to select the programming function. When depressed, the LED
placed above lights up and indicates that the monitor is in programming mode. The pa-
rameters of labeller and labelling are entered in the programming mode. The Figure
"PROGRAMMING menu tree" (page 14) shows the function tree of the programming
mode.
3.1.10 CONFIGURATION function key (4)
This key is used to select the configuration function. When depressed, the LED
placed above lights up and indicates that the monitor is in configuration mode. In this
mode the Collamat is adapted to the customer's requirements. The "CONFIGURATI-
ON menu tree" (page 25) shows the function tree of the configuration mode.
3.1.11 SERVICE DISPLAY function key (5)
This key is used to select the service display function. When depressed, the LED
placed above lights up and indicates that the monitor is in service mode. The "SERVICE
FUNCTIONS menu tree" (page 30) shows the function tree of the service mode.
ESC
5999.530-01E 14.01.2004 CSWM 4 10
