Conditions:
Multiple labelling mode and delayed predispensing mode exclude themselves mutually
The position adjustment should be smaller than the goods length. If not, the second phase follows
immediately the first one without waiting for the trailing edge of the goods.
The minimum distance between the goods must be greater than the position value plus predispen-
sing of the second labelling phase.
This distance is calculated as follows:
Predispensing - Stop position (When the predispensing length exceeds the
stop position length)
Label length - stop position (When the predispensing length is smaller than
the stop position length)
Note:
If the goods distance is shorter no labelling will be carried out !
5.11 Profiling (C9100 only)
The Profiling function is used, when a good with uneven surface should be labelled continuously.
The dispensing speed is constant when labelling with even surface. The speed has to be varied du-
ring labelling of goods with not even surface, so the label can be sticked on without folds.
After having activated Profiling enter the speed factor, then the start point and the length to be label-
led with normal speed. When the trailing edge of the label is reached before profiling is finished, it is
braked with normal brake ramp until predispensing. If the factor is set to 100 %, the function is not
activated. The function can be aborted with the ESC key. For more details see Technical Appendix.
PROFILING
Factor : 100 %
PROFILING PROFILING
Start : 50 mm Length : 30 mm
User level: programmer
Operating mode: STOP
5999.530-01E 14.01.2004 CSWM 4 27
