7.2 Error sequence
The Error sequence function is used to indicate the sequence of errors, occurred since calling up
this function. The last 21 errors are indicated at the most. The type of error is listed in the Technical
Appendix 'Error messages'. The display only indicates the error number.
The cause of a labelling error and a labeller failure can mostly be determined thanks to the error hi-
story. The following figure shows an example of such an indication:
ERROR LOGFILE
9, 0,14,14, 9, 9, 0
5, 7, 9, 9, 2, 8, 3
0,11,12, 9, 3, 8, 9
7.3 Self-test
The Self-test function is used to test the electronics of monitor and drive. The Self-test makes an
own menu available.
The 'SELF-TEST' menu tree indications are as follows:
SELFTEST
Test RAM
Test EEPROM
Test Keyboard
Test LED
Test LCD
Test Backlight
Test I/O Controller
Test I/O Monitor
Test Drive
7.3.1 Test RAM
The Test RAM function is used to test the RAMs of the monitor. A detected RAM error is indicated
as follows.
TEST RAM
Test ok
programmer/operator
RUN/STOP
User level:
Operating mode:
programmer
STOP
User level:
Operating mode:
